High Efficiency Hydraulic Industrial Dock Leveler WIth Push Button

SHANGHAI SUNCOME LOGISTICS EQUIPMENT CO.,LTD.

High Efficiency Hydraulic Industrial Dock Leveler WIth Push Button

Brand Name : SUNCOME

Model Number : Hydraulic dock leveler

Certification : CE/ISO9001:2008

Place of Origin : China

MOQ : 1 unit

Price : negotiation

Payment Terms : T/T

Supply Ability : 100 units per month

Delivery Time : 25 working days after received your payment

Packaging Details : No Package

Product Name : Hydraulic dock leveler

Application : Using for outside application

Thickness of Curtain : 20mm

Ambient Temperature : ≥-30 ℃

Working Range : +/-300mm above /below dock

Capacity : 25000-40000LBS

Power supply : 380V/3-Phase/50Hz/750W.

Control Unit : Push button

Color : Grey, Green

Contact Now

Hydraulic Industrial Dock Leveler WIth Push Button Smart And Safe Design


Our Team:


With more than ten years of rich experience, Suncome, a combination supplier of special industrial doors and loading/unloading system as well as an entrepreneur for the solution of logistics system,is the best choice of high-efficiency and energy savings in modern architectures and factories.


Our products are widely used in many fields such as food, pharmacy, chemical industries, electronics, auto manufacturers, precision machineries, clean rooms, refrigeration industries, intelligence building, automatic parking system, integrate with Europe advanced technology, notion, especially with high quality, affordable price, safety and durability.


We boast professional sales engineers, installation teams and after-sales service personnel who can provide our clients with customized service .


Automatic and High Performance Speed Door is the solution to the high-level clean environment which needs prevent dust and anti-bacteria, applied in the busy passageway area with high clearness demands,strong wind-resistance,especially for the food,pharmacy, and fine machining industry.


Specifications:

Technical Parameter

Max Size

7Ft(L)*10mm(W)

Lifting height

300mm above the dock leveler

Down height

300mm below the dock leveler

Capacity

25000-40000LBS

Control Unit

Control system

Push Button

Driving System

Hydraulic system

High performance hydraulic system

Driving Unit Brand

HaiPu Motor

Safety System

Safe Equipment

Free bumpers

Smart and safe design

Hold -down function

High volume hydraulic driving

Backing -wrenching pulling of chains

Sealing system

Dock seal, dock shelter and vehicle restraint.

Curtain Color

Grey, Green

Warranty

1 year Free warranty for the hydraulic lifting system

More Details:

  • Power supply: AC 380V, Three Phrase, 50HZ, 750w
  • Temperature: -30 to 65 Celsius degree
  • Standard operation: Push button
  • Pit Size: Long: from 1600mm to 2820mmWide: from 1870mm to 2170mm
  • Using Area: Loading and unloading area
  • Environmental protection: Yes
  • Low maintenance: Yes

Description:


1) Special design for factory’s outside/exterior application.

2) Frequent using/cycles during the loading and unloading.

3) Fine steel plate frame

4) Safe design&durable operation.

5) Structural safety legs supporting below-dock loading.

6) Integral maintenance structure for deck support

7) High volume&low pressure hydraulic activation system.

8) Traditional hydraulic way is a common tool for heavy lifting.

9) Environment friendly.

10) Single button operating system.
